THE PREMIER SERIES – SEMI-CUSTOM PROGRAM (continued)
Most wall and tall cabinets can be ordered with Mullion Doors Installed on the cabinet. All cope and
tenon tall doors greater than 48” high will have a center rail and two panel openings. A pack of assorted
shelf clips is included to align shelves with mullions.
Matching Interior is not standard with this option;
therefore, we recommend ordering cabinets with Finished Interior (FI)
. Reference the following chart for
door style availability.
When ordering MDIN, ALL standard doors will be replaced with mullion doors.
When ordering MDINTOP, TOP standard doors will be replaced with mullion doors.
When ordering MDINBTM, BOTTOM standard doors will be replaced with mullion doors.
To order, use the following codes with cabinet item code:
1MDIN — One Mullion Door Installed
2MDIN — Two Mullion Doors Installed
3MDIN — Three Mullion Doors Installed
4MDIN — Four Mullion Doors Installed
6MDIN — Six Mullion Doors Installed
8MDIN — Eight Mullion Doors Installed
For Example: W3930 2MDIN NG
To order, use the following codes with cabinet item code:
1MDINTOP — One Mullion Door Installed on top
2MDINTOP — Two Mullion Doors Installed on top
3MDINTOP — Three Mullion Doors Installed on top
4MDINTOP — Four Mullion Doors Installed on top
6MDINTOP — Six Mullion Doors Installed on top
8MDINTOP — Eight Mullion Doors Installed on top
For Example: U308424 2MDINTOP SSG
To order, use the following codes with cabinet item code:
1MDINBTM — One Mullion Door Installed on bottom
2MDINBTM — Two Mullion Doors Installed on bottom
3MDINBTM — Three Mullion Doors Installed on bottom
4MDINBTM — Four Mullion Doors Installed on bottom
6MDINBTM — Six Mullion Doors Installed on bottom
8MDINBTM — Eight Mullion Doors Installed on bottom
For Example: U308424 2MDINBTM SSG
These bullets apply to all Mullion Door Options:
• Not available on Box Only Options.
• Mullions in character maple and character cherry door styles will not have character features.
• Sandia will have the step profile on the top and bottom rails for Horizon Mullion Style.
• Half Arch and Symphony are only available in Essex, Henlow, Rose Hall, Seville and Madison door styles
on the following cabinets: W1530, W3030, W1533, W3033, W1536, W3036, W1539, W3039, W1542, W3042,
W1830, W3630, W1833, W3633, W1836, W3636, W1839, W3639, W1842 and W3642.
• For Wellington and Winslow door styles, the inside edge of the mullion door will match Messina.
• Harmony will have a decorative door frame with a mullion insert.
• Glass options are non-tempered and therefore not recommended for use near interior and exterior doors.
Glass patterns run vertically with the height of the door.
• Not available on the following cabinets: 9” Wide cabinets, entertainment cabinets, curved cabinets or any
open cabinets that do not come standard with doors.
INSET:
Available with Traditional Mullion Style only and for wall cabinets 15” high or higher and 15”
wide or wider. Not available on 24” wide double door cabinets. DDF options are available.
Note: To order replacement doors, use the Easy Parts Search Program on WAY.
See Premier–1–64 for Mullion Style and Glass Type options.
W3930 2MDIN NG
DC2730 1MDIN CG
U308424 2MDINTOP SSG
U308424 2MDINBTM SSG
MDIN — Mullion Doors Installed
MDINTOP — Mullion Doors Installed Top
MDINBTM — Mullion Doors Installed Bottom
