THE PREMIER SERIES – SEMI-CUSTOM PROGRAM (continued)
Many base, tall and vanity/office cabinets can be ordered with an Inverted Frame. Cabinet will have
a subfloor located above the drawer. Not available with Wide Top Rail option. See the Semi-Custom
Chart for option availability.
To order, add the following code with cabinet item code:
IF — Inverted Frame
For Example: B24 IF
Note: When ordering IF option for utility cabinets, the larger doors (which will now be on top) for arch
and cathedral door styles will become arch and cathedral. The smaller doors will be square.
Pricing
Add 30% to List Price
B24 IF
U248424 IF
Pricing
Add 25% to List Price
Peninsula
Side
Kitchen
Side
Many wall and base cabinets are available as a peninsula cabinet. See the Semi-Custom Chart for option
availability.
To order, use the following code with cabinet item code:
P — Peninsula
For Example: W3942 P
B21 R P
Note: For single door peninsula cabinets, kitchen side and peninsula side will be hinged the same.
For
Example: If you specify right hinge, the kitchen side will be right hinged and the peninsula side will be
right hinged.
Note: When ordering Finished Matching Ends for Diagonal Corner Cabinets, choose both left and right so
cabinet remains reversible.
For Diagonal Corner, Diagonal Corner Sink Base and Corner Sink Base Cabinets with Peninsula Option,
you will need to specify Peninsula Right (PR) and Peninsula Left (PL). Always remember to face the cabinet
when specifying left and right.
B21 R P
W3942 P
Pricing
Add 60% to List Price
DOOR
24
12
12
Peninsula
Left Shown
DRB33 RDDWR15
B30 RDDWR18
Pricing
No Charge
The Removable Front option is only available for Soffit Cabinets. This option creates a removable
front by adding clips to keep the front in place. This allows the front to be removed for inspection.
To order, use the following code with cabinet item code:
RF — Removable Front
For Example: SOF481824 RF
SOF481824 RF
This option is available on most 24” deep base cabinets with a drawer(s). It shortens the depth of the
drawers to the chosen dimension by adding a sub-back while not changing the overall cabinet depth.
This option applies to all drawers in the cabinet.
To order, use the following codes with cabinet item code:
RDDWR18 — Reduce drawer depth to 18”
RDDWR15 — Reduce drawer depth to 15”
RDDWR12 — Reduce drawer depth to 12”
RDDWR9 — Reduce drawer depth to 9”
For Example: DRB33 RDDWR15
B30 RDDWR18
IF — Inverted Frame
P — Peninsula
RDDWR — Reduced Depth Drawer
RF — Removable Front Option
