Wellborn Select & Premier Specification Book

356 / 878

Premier–1–68
THE PREMIER SERIES – SEMI-CUSTOM PROGRAM (continued)
Semi-Custom APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL •
INS •
WIDTH HEIGHT DEPTH
Min. Max. Min. Max. Min. Max.
24
MDEP ID24
MVEP ID24
14
MWEP ID14
25, 26, 27, 30, 32
341/ 2
(2) Doors
Mitered Door Styles
MBEP ID27, Slab.idw
341/2
25, 26, 27, 30, 32
Slab Door Styles
MTEP ID27, 30, 32 Slab.idw
84
90
93
96
25, 26, 27, 30, 32
Slab Door Styles
PP18W ID15
15
84
90
96
25, 26, 27, 30, 32
Mitered Door Styles
(4) Doors
Many wall, base, tall and vanity/office accessories can be increased in depth up to 24”, mantle shelves
to 27”, refrigerator end panels to 30” and tall and base end panels to 32”. When ID is chosen, the item's
depth is increased to the specified dimension. See the Semi-Custom Chart for option availability.
To order, use the following codes with item code:
ID5 — Increase wall depth to 5”
ID6 — Increase wall depth to 6”
ID7 — Increase wall depth to 7”
ID8 — Increase wall depth to 8”
ID9 — Increase wall depth to 9”
ID10 — Increase wall depth to 10”
ID11 — Increase wall depth to 11”
ID12 — Increase wall depth to 12”
ID13 — Increase wall depth to 13”
ID14 — Increase wall depth to 14”
ID15 — Increase wall depth to 15”
ID16 — Increase wall depth to 16”
ID17 — Increase wall depth to 17”
ID18 — Increase wall depth to 18”
ID19 — Increase wall depth to 19”
ID20 — Increase wall depth to 20”
ID21 — Increase wall and vanity/office depth to 21”
ID22 — Increase wall depth to 22”
ID23 — Increase wall depth to 23”
ID24 — Increase wall and vanity/office depth to 24”
ID25 — Increase base and tall depth to 25”
ID26 — Increase base and tall depth to 26”
ID27 — Increase base and tall depth and mantle shelf depth to 27”
ID30 — Increase refrigerator end panel depth to 30”
ID32 — Increase tall end panel depth to 32”
For Example: MWEP ID14
Matching Wall End Panel
1. The maximum increase for Matching Wall End Panel is 24”
2. Matching Wall End Panels can be increased to the inch only (1⁄2”, 3⁄4”, etc. are not available)
3. Over ID21 will have a double end panel except for mitered door styles.
4. For inset, use Integrated Matching End option.
To order, use the following codes with item code:
ID13 — Increase wall end panel to 13”
ID14 — Increase wall end panel to 14”
ID15 — Increase wall end panel to 15”
ID16 — Increase wall end panel to 16”
ID17 — Increase wall end panel to 17”
ID18 — Increase wall end panel to 18”
ID19 — Increase wall end panel to 19”
ID20 — Increase wall end panel to 20”
ID21 — Increase wall end panel to 21”
ID22 — Increase wall end panel to 22”
ID23 — Increase wall end panel to 23”
ID24 — Increase wall end panel to 24”
Matching Vanity End Panel & Matching Desk End Panel
1. The maximum increase for Matching Vanity and Matching Desk End Panels is 24”
2. Matching Vanity and Matching Desk End Panels can be increased in 3” increments only.
3. End panels will be double panel except on mitered door styles.
4. For inset, use Integrated Matching End option.
To order, use the following codes with item code:
ID21 — Increase vanity end panel to 21”
ID24 — Increase vanity end panel and desk end panel to 24”
Matching Tall End Panel & Matching Base End Panel
1. The maximum increase for Matching Tall and Matching Base End Panels is 32”
2. End panels will be double panel except slab door styles.
3. For inset, use Integrated Matching End option.
To order, use the following codes with item code:
ID25 — Increase tall end panel and base end panel to 25”
ID26 — Increase tall end panel and base end panel to 26”
ID27 — Increase tall end panel and base end panel to 27”
ID30 — Increase tall end panel and base end panel to 30”
ID32 — Increase tall end panel and base end panel to 32”
Pricing
Add 23% to List Price
ID — Increased Depth
