367 / 878
Premier–1–79
THE PREMIER SERIES – SEMI-CUSTOM PROGRAM (continued)
6
W2430 WTR6
3
27
W2430 WTRRO3
3
W2430 P WTR3P
3
U248424 WTR3
6
U248424 WTR6
Available in 3” and 6”. Cabinet interior does not extend in height. The door and cabinet box size does
not change. Not available with Clipped Corner, Inverted Frame or Valance options. Peninsula option is
available. If selected, both frames will be extended.
If ordering WTR option and a full height end panel is needed, you can order Finished Cabinet End (FCE) or
Matching Finished End (MFE) and the end panel will increase in height to match the extended rail height.
Wall and Tall cabinet specifications:
Available in 3” or 6”. If FI option is specified, end panels will automatically be full height finished ends.
Toe Kick Unattached required for all tall cabinets over 102” high. See Semi-Custom chart for availability.
To order, use the following codes with cabinet item code:
WTR6 — Wide Top Rail
WTR3 — Wide Top Rail
For Example: W2430 WTR6
For Example: W2430 WTR3
To order Peninsula option, use the following codes with cabinet item code:
WTR6P — Wide Top Rail Peninsula
WTR3P — Wide Top Rail Peninsula
For Example: W2430 P WTR6P
For Example: W2430 P WTR3P
Base and Vanity cabinet specifications:
The drawer is removed and replaced with a solid wood rail. The door and cabinet box size does not
change. Not available on Full Height door vanity or Full Height door base cabinets. Many base, vanity
and office cabinets are available with the WTR option. See Semi-Custom Chart for availability.
To order, use the following codes with cabinet item code:
WTR — Wide Top Rail
For Example: B24 WTR
To order Peninsula option, use the following codes with cabinet item code:
WTRP — Wide Top Rail Peninsula
For Example: B24 P WTRP
Wide Top Rail Reduced Opening is available for wall and tall cabinets. It shortens the height of the
door and creates a wide top rail that is available in 3” or 6” heights. This option is not available for 12”
high cabinets and will only be available in the 3” height for 15” high cabinets. These restrictions also
apply to the upper section of tall cabinets that line up with 12” and 15” high cabinets. Not available
with Clipped Corner, Inverted Frame or Valance options. When this option is ordered in conjunction
with Functional End, Integrated Matching End, Matching End Panel Installed or Peninsula Options,
the modified sides will also reflect the Wide Top Rail Reduced Opening.
To order, use the following codes with cabinet item code:
WTRRO3 — Wide Top Rail Reduced Opening by 3”
WTRRO6 — Wide Top Rail Reduced Opening by 6”
For Example: W2430 WTRRO3
To order Peninsula option, use the following codes with cabinet item code:
WTRRO3P — Wide Top Rail Reduced Opening Peninsula by 3”
WTRRO6P — Wide Top Rail Reduced Opening Peninsula by 6”
For Example: W2430 P WTRRO3P
*
Dimension to top of Door
TOL = 7
1
⁄
4
”
FOL = 6
11
⁄
16
”
INS = 8
3
⁄
4
”
* Dimension to top of Door
1/2" Overlay =7 "
1
/
4
Full Overlay = 6 "
11
/
16
B24 WTR
* Dimension to top of Door
1/2" Overlay = 7
1
/
4
"
Full Overlay = 6
11
/
16
"
B24 P WTRP
Pricing
Add $165 List
Pricing
Add $165 List
WTR — Wide Top Rail
WTRRO — Wide Top Rail Reduced Opening
Semi-Custom
APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL
•
INS
•
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
