344 / 878
Premier–1–56
THE PREMIER SERIES – SEMI-CUSTOM PROGRAM (continued)
Custom Appliance Panels to match your Estate cabinetry are available for appliances designed to accept them. These panels
will be custom made to the appliance manufacturer specifications. It is important to research your appliances thoroughly before
ordering. A few minutes spent acquiring the correct documents eliminates expensive replacements and order delays. Check the
manufacturers specifications and model number carefully to verify your particular application. A complete model number and
the appropriate manufacturer’s specifications must accompany all custom panel orders.
List Price
Item Code
Description
TOL
&
FOL INS
CUSTRP30CL
30” REF PNL, CLASSIC
$1541
$2003
CUSTRP30CLWTG 30” REF PNL, CLASSIC, W/GRILL PNL
$1731
$2250
CUSTRP30OL
30” REF PNL, OVERLAY
$1541
$2003
CUSTRP30OLWTG 30” REF PNL, OVERLAY, W/GRILL PNL
$1731
$2250
CUSTRP36CL
36” REF PNL, CLASSIC
$1541
$2003
CUSTRP36CLWTG 36” REF PNL, CLASSIC, W/GRILL PNL
$1731
$2250
CUSTRP36OL
36” REF PNL, OVERLAY
$1541
$2003
CUSTRP36OLWTG 36” REF PNL, OVERLAY, W/GRILL PNL
$1731
$2250
CUSTRP42CL
42” REF PNL, CLASSIC
$1839
$2391
CUSTRP42CLWTG 42” REF PNL, CLASSIC, W/GRILL PNL
$2055
$2672
CUSTRP42OL
42” REF PNL, OVERLAY
$1839
$2391
CUSTRP42OLWTG 42” REF PNL, OVERLAY, W/GRILL PNL
$2055
$2672
CUSTRP48CL
48” REF PNL, CLASSIC
$2082
$2707
CUSTRP48CLWTG 48” REF PNL, CLASSIC, W/GRILL PNL
$2325
$3023
CUSTRP48OL
48” REF PNL, OVERLAY
$2082
$2707
CUSTRP48OLWTG 48” REF PNL, OVERLAY, W/GRILL PNL
$2325
$3023
CUSTRP30OLF2S
30” REF PNL, OVERLAY, Finished Both Sides
$1849
$2404
CUSTRP30OLWTGF2S 30” REF PNL, OVERLAY, W/GRILL PNL, Finished Both Sides $2077
$2700
CUSTRP36OLF2S
36” REF PNL, OVERLAY, Finished Both Sides
$1849
$2404
CUSTRP36OLWTGF2S 36” REF PNL, OVERLAY, W/GRILL PNL, Finished Both Sides $2077
$2700
CUSTRP42CLWTGF2S 42” REF PNL, OVERLAY, W/GRILL PNL, Finished Both Sides $2466
$3206
CUSTRP42OLF2S
42” REF PNL, OVERLAY, Finished Both Sides
$2207
$2869
CUSTRP42OLWTGF2S 42” REF PNL, OVERLAY, W/GRILL PNL, Finished Both Sides $2466
$3206
CUSTRP48OLF2S
48” REF PNL, OVERLAY, Finished Both Sides
$2498
$3248
CUSTRP48OLWTGF2S 48” REF PNL, OVERLAY, W/GRILL PNL, Finished Both Sides $2790
$3628
Notes:
•Any cut outs required for
dispensers must be done in the
field.
•Custom routing for finger clearance
is not available.
•Panels greater than 24” in width
will have two vertical panels.
Mitered door styles have two
separate panels designed to be
mounted side-by-side.
•Panels greater than 48” in height
will have two panels separated by a
center rail. Mitered door styles will
always have one tall panel with no
center rail.
•Grill panels and doors less than 8”
will have a flat center panel even in
raised panel door styles.
•Add percentage (%) upcharge for
specialty finishes.
Typical “Overlay” Application
Custom panels for an “Overlay” application typically
include
3
⁄
16
” backers,
1
⁄
8
” spacers and
3
⁄
4
” custom panels which
match the specified door style. The panels cover the entire
front of the refrigerator and the installation usually requires
a custom handle, but in some applications the standard
handle can be extended to allow finger clearance between
the custom panel and the handle. The term “Overlay” does
not mean that the panels are limited to a full overlay door
style. Traditional overlay doors can be used as well.
Typical “Classic” or “Framed” Application
Custom panels for a “Classic” application include
3
⁄
16
”
backers and
3
⁄
4
” custom panels that match the specified
door style. Some manufacturers refer to this as a “Framed”
application. In this application, the trim around the
perimeter of the door which holds the panels in place is
visible. There is typically a 2”- 3” reveal on the handle
side of the panels to allow for finger clearance. The top,
bottom and hinge side reveals vary from
5
⁄
16
”- 1” depending
on the manufacturer.
Typical Overlay Configurations
Typical Classic Configurations
CUSTRP42OLWTG
CUSTRP30OLWTG
CUSTRP30OL
Inset Design
Custom Refrigerator Door Panels
