342 / 878
Premier–1–54
THE PREMIER SERIES – SEMI-CUSTOM PROGRAM (continued)
Clipped Corner cabinets are available on many wall, base, vanity/office and tall cabinets. The clipped
corner end panel is set back 3” by the clip and the width of the cabinet will increase 3” per clip. For
example, a B24 with one clipped corner will have a 27” width. Clipped Corner sides are unfinished.
Choose FME to get a finished end. See the Semi-Custom Chart for option availability.
To order use the following codes with cabinet item code:
CCR — Clipped Corner Right Wall, Base and Vanity/Office
CCL — Clipped Corner Left Wall, Base and Vanity/Office
CCRT — Clipped Corner Right Tall
CCLT — Clipped Corner Left Tall
CCFR — Clipped Corner Fluted Right Wall, Base and Vanity/Office
CCFL — Clipped Corner Fluted Left Wall, Base and Vanity/Office
CCFRT— Clipped Corner Fluted Right Tall
CCFLT— Clipped Corner Fluted Left Tall
For Example: B24 CCL (Left)
B24 CCFL (Fluted Left)
To order Clipped Corner with Peninsula option for wall, base, vanity/office, use the following codes
with cabinet item codes:
CCRP — Clipped Corner Right on Kitchen Side and Peninsula Side
CCLP — Clipped Corner Left on Kitchen Side and Peninsula Side
CCFRP— Clipped Corner Fluted Right on Kitchen Side and Peninsula Side
CCFLP — Clipped Corner Fluted Left on Kitchen Side and Peninsula Side
Note: Must be ordered with peninsula option only.
For Example: B24 P CCLRP (Left Peninsula)
B24 P CCFLP (Fluted Left Peninsula)
* The depth of a cabinet with a Clipped Corner cannot be less than 9”
B24P CCFLP
24
3
B24 P CCFLP
(Peninsula Clipped Corner
Fluted Left Base)
27” Overall cabinet width
B24 CCL
24
3
B24 CCL
(Clipped Corner Left Base)
27” Overall cabinet width
Pricing
Add $275 List per end (Wall, base and vanity)
Add $330 List per end (Tall)
Add $550 List per end (Peninsula wall, base and vanity)
Pricing
Add 40% to List Price
This option replaces the back of the cabinet with a bead board panel in a different finish and/or wood
species. It is available for most Wall, Base, Bookcase and Furniture Bookcase cabinets. All cabinets that
are standard with a finished interior will come with the bead board back in the specified finish and
wood species. Any cabinets with a standard interior will require ordering one of the many available
finished interior options before this option will be allowed: Finished Interior (FI), Finished Interior
Finished Door (FIFD), Finished Interior Mullion Door (FIMD) or Finished Interior Decorative Door
Frame (FIDDF). Cabinets with this option are not available over 96" high. See the individual options
for details and availability.
Note:
When choosing this option specialty techniques will
NOT
be applied to the Contrasting
Bead Board Back
To order, use the following code with cabinet item code:
CBB — Contrasting Bead Board Back + Species + Contrasting Finish Code
For Example: BKC2196 CBB MPL SAG MOC
BKC2196 CBB
WSC2454 CBB
Semi-Custom
APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL
•
INS
•
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
CBB — Contrasting Bead Board Back
CC — Clipped Corner
