Premier–1–60

THE PREMIER SERIES – SEMI-CUSTOM PROGRAM (continued)

Functional End option is available for use on many wall, base, desk and vanity cabinets. See each section for information regarding

vailability of Modify Depth option and sizing information.

INSET:

Not available

When adding a Functional End, please note the following:

• 24” Deep cabinets are available with one door or two doors on the functional end.

• Single door Functional End will be hinged at the back of cabinet. Allow proper clearance for door to open.

• Must specify left, right or both sides of the cabinet.

• When FH, FIFD, FIMD or IF option is selected, the option will apply to front and functional end side of cabinet.

Note: When choosing Functional End option, the following options are excluded: BO, CC, ES, FO, P, RTK, TKU, VT, MTLDINSG,

MTLDINRG, MTLDFGINSG, MTLDFGINRG, SSDSCIN, SSWIN, SDWIN and TOTIN.

Wall cabinets:

• Full-height door cabinets receive one full-height functional door by specifying FEWL or FEWR. When MD24 is

specified, then the cabinet will have the option of one or two doors on the Functional End. In order to specify

two doors on the Functional End use FEWL2 and FEWR2 codes.

• 9” Depth cabinets with Functional End will have a square door for TOL arch and all cathedral door styles.

To order, use the following codes with cabinet item code:

FE — Functional End

For Example:

1 Door per side

1 Door per side

2 Doors per side

W3936 FEWL (1 Door)

W3936 MD24 FEWL (1 Door) W3936 MD24 FEWL2 (2 Doors)

W3936 FEWR (1 Door)

W3936 MD24 FEWR (1 Door) W3936 MD24 FEWR2 (2 Doors)

W3936 FEWB2 (2 Doors) W3936 MD24 FEWB2 (2 Doors) W3936 MD24 FEWB4 (4 Doors)

FE Available on the following cabinets:

W960 - W4812, PW1548 - PW3660

Base, Desk and Vanity cabinets:

• Full-height door cabinets receive one full-height functional door by specifying FEL or FER. Two doors can be

specified for 24” depth cabinets by using FEL2 and FER2 codes. Drawer/door combination cabinets receive a

drawer front/functional door combination to match. Drawer front on the FE side is not functional.

• All base cabinets have square doors.

• Vanity bases with arch doors selected will come standard with arch doors on the functional end.

• Cabinets with this option will come standard with full depth shelving.

• Recessed Toe Kick will come standard on both front and functional end.

• When Inverted Frame option is selected, both face frames will be inverted.

To order, use the following codes with cabinet item code:

FE — Functional End

For Example:

1 Door per side

1 Door per side

2 Doors per side

B24 FEL (1 Door)

B24 MD21 FEL (1 Door)

B24 FEL2 (2 Doors)

B24 FER (1 Door)

B24 MD21 FER (1 Door)

B24 FER2 (2 Doors)

B24 FEB2 (2 Doors) B24 MD21 FEB2 (2 Doors) B24 FEB4 (4 Doors)

FE Available on the following cabinets:

B12 - B48, SB24 - SB60, VS1816 - VS42B18, VSB36 - VSB60, VB12 - VB2418, VS21BH - VS42B18BH, VSB36BH -

VSB60BH, VB12BH - VB2418BH and DVB15 - DVB36

W3936 FEWL

B15 FEL2

VS21 FEL

Decorative Door Frame Functional End Option

• Available on Wall, Base, Desk and Vanity cabinets

• When any Decorative Door Frame option is selected for the front face of the cabinet, the functional end door

will automatically match the front. Refer to Decorative Door Frame options for details.

To order, use the following codes with cabinet item code:

FE — Functional End

For Example: W3936 2DDFIN CG FEWL

Mullion Door Functional End Option

• Available on Wall cabinets

• When any Mullion Door option is selected for the front face of the cabinet, the functional end door will

automatically match the front unless, for overlay door styles, the cabinet is less than 15” high or 12” wide.

For wide stile door styles, mullion doors are not available for doors less then 13

1

4

” wide.

If a mullion door is

not available for the specified cabinet a finished door will be substituted. Refer to Mullion Door options for

details.

To order, use the following codes with cabinet item code:

FE — Functional End

For Example: W3936 2MDIN TR NG FEWL

W3936 FEWL DDFIN CG

W3936 FEWL MDIN TR NG

FE — Functional End
