93 / 878
Select –2–33
13
11
/
16
19
11
/
16
9
/
16
• Silver metallic in color
• Use with standard wood hoods on
Select–2–31 and Select–2–32
• Includes charcoal filter
WHL30
WHL36
Wood Hood Liner
DCK02
(for PFU02)
DCK04
(for PFU04)
Ductless Conversion Kit
18
1
/
4
4
28
7
/
16
, 34
7
/
16
11
1
/
2
20 24
PFU02
Power Fan Unit (390 CFM)
• 390 CFM with 7” round discharge
• Requires DCK02 ductless conversion kit
for in-home venting
• Back draft damper included
• Lighted fan unit with easy clean stainless
finish
• Pre-wired for electrical connection
• UL, CUL, HVI certified
• Used in all wood hoods on Select–2–31 and
Select–2–32 and IWH3624P, IWH3624B,
IWH3624, IWH3024P, IWH3024B and
IWH3024
• Liner must be ordered separately
• Top access to hood interior is required to
complete installation
• 290 CFM with 7” round discharge
• Requires DCK04 ductless conversion kit
for in-home venting
• Back draft damper included
• Lighted fan unit with easy clean silver
metallic finish
• Pre-wired for electrical connection
• UL, CUL, HVI certified
• Used in all wood hoods on Select–2–31 and
Select–2–32 and IWH3624P, IWH3624B,
IWH3624, IWH3024P, IWH3024B and
IWH3024
• Liner must be ordered separately
• Top access to hood interior is required to
complete installation
PFU04
Power Fan Unit (290 CFM)
HOOD ACCESSORIES (continued)
11
7
/
16
7
1
/
2
17
1
/
4
13
11
/
16
19
11
/
16
9
/
16
11
7
/
16
"
7
1
/
2
"
19
11
/
16
"
13
11
/
16
"
17
1
/
4
"
• Silver metallic in color
• Use with standard Integral Wood Hoods on
Select–2–28 and Select–2–29
• IWHL42 for use with PFU06 only
IWHL30
IWHL36
IWHL42
TED812
Integral Wood Hood Liner
Transition Elbow Duct
28
3
/
16
, 34
3
/
16
, 40
3
/
16
4
24
7
/
16
, 30
7
/
16
, 36
3
/
16
18
7
/
16
10
15
/
16
When ordering any wood hood, it is the dealer’s responsibility to verify all fire codes in your area (fire codes vary from state to state and even from city to city). Hoods should
be installed at a proper level over the range and installer should account for any special needs for cook tops and grills. Be sure to match hood liner width to ensure proper
ventilation. Please note that these are only recommendations and you should always reference local building codes, fire codes and manufacturer specifications for final design/
applications. Recommended distance from top of cooking surface to bottom of fan unit is 24”-30” depending on manufacturer range specifications and depth of cabinets. If
installed beyond recommended distance, the fan unit will not perform effectively.
17
1
/
4
8
7
/
8
13
5
/
8
19
5
/
8
11
3
/
8
• Silver Metallic in color
• Use with PFU06
• 8” Diameter and 12” in height
• Adjustable
