Select –2–31
CWHFLK36
CWHFLK42
CWHFLK48
CWHFLK54R
CWHFLK60
CWHFLK66
PCWHFLK36
PCWHFLK42
PCWHFLK48
PCWHFLK54
• Requires two 50 watt halogen lights
• 710 CFM
• 3 Speed switch
• Aluminum filter
• Sirocco fan unit (weight 35.2 lbs.)
• Noise level = 7 sone at max speed
• 8” Diameter duct
• Liner and fan have stainless steel finish
• Top access to hood interior is required to
complete installation
34
1
⁄
2
” for (ACWH3630, ACWH3636, ACWH3642, ACWH3648,
CCWH3630, CCWH3636, CCWH3642, CCWH3648,
CWH36P, CWH36B, CWH36D, CWH36PNAV,
CWH36BNAV, IWHM3624, IWHM3630, IWHM3636,
IWHM3642, IWHM3648, IWHM3654, TWH3624,
TWH3630, TWH3633, TWH3636)
40
1
⁄
2
” for (ACWH4230, ACWH4236, ACWH4242, ACWH4248,
CCWH4230, CCWH4236, CCWH4248, CWH42P,
CWH42B, CWH42D, CWH42PNAV, CWH42BNAV,
IWHM4224, IWHM4230, IWHM4236, IWHM4242,
IWHM4248, IWHM4254, TWH4224, TWH4230,
TWH4233, TWH4236)
46
1
⁄
2
” for (ACWH4830, ACWH4836, ACWH4842, ACWH4848,
CCWH4830, CCWH4836, CCWH4848, CWH48P,
CWH48B, CWH48D, CWH48PNAV, CWH48BNAV,
IWHM4824, IWHM4830, IWHM4836, IWHM4842,
IWHM4848, IWHM4854, TWH4824, TWH4830,
TWH4833, TWH4836)
52
1
⁄
2
” for (ACWH5430, ACWH5436, ACWH5442, ACWH5448,
CCWH5430, CCWH5436, CCWH5442, CCWH5448,
CWH54P, CWH54B, CWH54PNAV, CWH54BNAV,
IWHM5424, IWHM5430, IWHM5436, IWHM5442,
IWHM5448, IWHM5454, TWH5424, TWH5430,
TWH5433, TWH5436)
58
1
⁄
2
” for (IWHM6024, IWHM6030, IWHM6036)
64
1
⁄
2
” for (IWHM6624, IWHM6630, IWHM6636)
Chimney Wood Hood Fan and Liner Kit
10
7
/
16
27
16
7
/
8
19
13
/
16
25
1
/
16
15
9
/
16
21
7
/
16
Liner
Liner
34
1
⁄
2
, 40
1
⁄
2
, 46
1
⁄
2
,
52
1
⁄
2
, 58
1
⁄
2
, 64
1
⁄
2
,
HOOD FAN AND LINER KITS
10
7
/
16
27
16
7
/
8
19
13
/
16
25
1
/
16
15
9
/
16
28
7
/
16
Liner
34
1
/
2
, 40
1
/
2
, 46
1
/
2
Liner
, 52
1
/
2
34
1
⁄
2
” (for PCWH36P, PCWH36B, PCWH36D, PCWH36PNAV,
PCWH36BNAV, PACWH36)
40
1
⁄
2
” (for PCWH42P, PCWH42B, PCWH42D, PCWH42PNAV,
PCWH42BNAV, PACWH42)
46
1
⁄
2
” (for PCWH48P, PCWH48B, PCWH48D, PCWH48PNAV,
PCWH48BNAV, PACWH48)
52
1
⁄
2
” (for PCWH54P, PCWH54B, PCWH54D, PCWH54PNAV,
PCWH54BNAV, PACWH54)
Peninsula Chimney Wood Hood Fan and Liner Kit
• Requires two 50 watt halogen lights
• 650 CFM
• 3 Speed switch
• Aluminum filter
• Sirocco fan unit (weight 35.2 lbs.)
• Noise level = 7 sone at max speed
• 8” Diameter duct
• Liner and fan have stainless steel finish
• Top access to hood interior is required to
complete installation
HOODS
• (2) Doors must be ordered separately to
field install
• Spindle Rail and Posts included; must be
field installed
•
Ledge is ¾” thick and extends 2¾” from
cabinet
• Not available in Thermofoil, Laminate
and MDF door styles
Door Sizes for:
WH3024 TOL 12½” x 15½”
FOL 14
5
⁄
8
” x 17
1
⁄
8
”
WH3624 TOL 15½” x 15½”
FOL 17
5
⁄
8
” x 17
1
⁄
8
”
WH3024
WH3624
24” High Wood Hood
Door Sizes for:
WH3030 TOL 12½” x 21½”
FOL 14
5
⁄
8
” x 23
1
⁄
8
”
WH3630 TOL 15½” x 21½”
FOL 17½” x 23
1
⁄
8
”
WH3030
WH3630
30” High Wood Hood
For all Wood Hoods, a power fan unit with light (PFU04/PFU02) is required. A ductless conversion kit (DCK04/DCK02) must be ordered
if venting inside the home. All hoods have plywood fronts and end panels. Additional moulding may be required to cover bottom plywood edges.
Metal liner is sold separately.
• (2) Doors must be ordered separately to
field install
• Spindle Rail and Posts included; must be
field installed
•
Ledge is ¾” thick and extends 2¾” from
cabinet
• Not available in Thermofoil, Laminate
and MDF door styles
22
1
/
2
12
24
30, 36
19
9
/
16
12
30
19
9
/
16
30, 36
NEW
CODE
