Premier–2–47
54”, 51” & 48” High Angle Wall Stack Cabinets
AWCSC1254L L/R
AWCSC1254R L/R
AWCSC1251L L/R
AWCSC1251R L/R
AWCSC1248L L/R
AWCSC1248R L/R
2 Doors,
2 Adj. shelves
•
Must specify L or R hinge
• Ends are unfinished
1 Door,
3 Adj. shelves
AW42 L/R
AW39 L/R
42” & 39” High Angle Wall Corner Cabinet
42,
39
12
12
17
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
36
1
/
4
” 42”
42” High Angle Wall Stack Cabinets
AWCSC1242L L/R
AWCSC1242R L/R
2 Doors,
2 Adj. shelves
Semi-Custom
APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL
• •
• • • • • • •
• •
•
ANGLE WALL CABINETS (continued)
RL
RR
LL
LR
RL
RR
LL
LR
22
1
/
2
°
24
45°
12
12
17
22
1
/
2
°
22
1
/
2
°
24
45°
12
12
17
22
1
/
2
°
•
Must specify L or R hinge
• Outside angle is 225°
• IME & MFE options available for 12” side
only
• Degrees shown on diagram are for use
when cutting moulding
• Upper section is 18” high and lower
section is 36” high for overall 54” height,
33” high for overall 51” height and 30”
for overall 48” height
• Bottom door is always square
• FOL reveal is
7
⁄
8
” between top and bottom
doors
• TOL reveal is 2
1
⁄
2
” between top and
bottom doors
•
INSET:
Not available
•
Must specify L or R hinge
• Outside angle is 225°
• IME & MFE options available for 12” side
only
• Degrees shown on diagram are for use
when cutting moulding
• Upper section is 12” high and lower
section is 30” high for overall 42” height
• Bottom door is always square
• FOL reveal is
7
⁄
8
” between top and bottom
doors
• TOL reveal is 2
1
⁄
2
” between top and
bottom doors
• Top door is not available with mullion
doors
•
INSET:
Not available
Semi-Custom
APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL
• •
s
• • •
• •
• •
•
INS
• •
s
• • •
• •
• •
•
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
42” 54”
17
(diagonal width)
54,
51,
48
12
12
24
18
36,
33,
30
17
(diagonal width)
42
12
12
24
12
30
