Select –11–13
HINGE SPECIFICATIONS
WELLBORN CABINET HINGE SPECIFICATIONS – SELECT SMOOTH CLOSE HINGES
ITEM # DESCRIPTION
CABINET OR STYLE
C1108 1
1
⁄
2
” O/L,
7
⁄
16
” Cup Depth, 6-way Adjustability 30” & 36” Full Overlay utility cabinets without center mullion
C1103 1
9
⁄
16
” O/L,
7
⁄
16
” Cup Depth, 6-way Adjustability Madison, Savannah, Seville and Sydney doors
C1105 1
9
⁄
16
” O/L, ½” Cup Depth, 6-way Adjustability All Full Overlay doors, except Madison, Savannah, Seville and Sydney
C1107 ¾” O/L,
7
⁄
16
” Cup Depth, 6-way Adjustability All Full Overlay DCs and ½” Overlay, ½” Overlay 9” wide cabinets
C1106
7
⁄
16
” O/L,
7
⁄
16
” Cup Depth, 6-way Adjustability All ½” Overlay cabinets
C1109
1
⁄
2
” O/L,
7
⁄
16
” Cup Depth, 6-way Adjustability All Traditional Overlay with Smooth Close Hinge option
WELLBORN CABINET HINGE SPECIFICATIONS – SELECT
ITEM # DESCRIPTION
CABINET OR STYLE
C2232 1
1
⁄
2
” O/L,
7
⁄
16
” Cup Depth, 6-way Adjustability 30” & 36” Full Overlay utility cabinets without center mullion
C2207 1
9
⁄
16
” O/L,
1
⁄
2
” Cup Depth, 6-way Adjustability All Full Overlay
C2208
3
⁄
4
” O/L,
7
⁄
16
” Cup Depth, 6-way Adjustability All Full Overlay DCs; Traditional Overlay RAWs; Traditional Overlay 9” wide cabinets
C2187 170˚ Hinge
Full Overlay CSBs and ERC24s
C2188 FOL Mounting Plate
Full Overlay CSBs and ERC24s
C2187 170˚ Hinge
Traditional Overlay CSBs and ERC24s
C2190
1
⁄
2
” O/L Mounting Plate
Traditional Overlay CSBs and ERC24s
C2214
7
⁄
16
” O/L,
7
⁄
16
” Cup Depth, 6-way Adjustability All Traditional Overlay Select cabinets, except Franklin and Imperial
C2191 Center Pie Cut Hinge
Center hinge on CSB doors
C2192 Mounting Plate
Mounting plate on CSB doors
C2265 Polished Brass Mirror Hinge
All TVs, CTVLs & MCs
C2267 Polished Brass Strike Plate
All TVs, CTVLs & MCs
C2273 Chrome Mirror Hinge
All TVs, CTVLs & MCs
C2274 Chrome Strike Plate
All TVs, CTVLs & MCs
C2240
1
⁄
2
” O/L,
7
⁄
16
” Cup Depth, 6-way Adjustability Franklin and Imperial
