Select –11–11
Sidemount Drawer Slides
Description
24” Deep
Item Code
21” Deep
Item Code
18” Deep
Item Code
Right Slide for Bottom Drawer in Standard Construction C2925 C2927 C2931
Left Slide for Bottom Drawer in Standard Construction C2924 C2926 C2930
Right Slide for all other Drawers in Standard Construction C2101 C2103 C2929
Left Slide for all other Drawers in Standard Construction C2100 C2102 C2928
Right Bracket for Bottom Drawers in Standard Construction DRB Cabinets C3061 C2130 C3061
Left Bracket for Bottom Drawers in Standard Construction DRB Cabinets C3060 C2130 C3060
Ball Bearing Slide for Bottom Drawer in Standard Construction DRB Cabinets C2129 C2126 C2124
Right Bracket for next to Bottom Drawer in Standard Construction DRB Cabinets C3061 C3061 C3061
Left Bracket for next to Bottom Drawer in Standard Construction DRB Cabinets C3060 C3060 C3060
Ball Bearing Slide for next to Bottom Drawers in Standard Construction DRB Cabinets C2129 C2126 C2124
Bracket for Peninsula Drawers in Standard Construction C3066 C3066 C3066
Right Slide for Peninsula Drawers in Standard Construction C2925 C2927 C2931
Left Slide for Peninsula Drawers in Standard Construction C2924 C2926 C2930
Undermount Drawer Slides
Description
24” Deep
Item Code
21” Deep
Item Code
18” Deep
Item Code
Right Bracket for Bottom Drawer in PWD & APC Construction C2940 C2940 C2940
Left Bracket for Bottom Drawer in PWD & APC Construction C2939 C2939 C2939
Right Bracket for all other drawers in PWD & APC Construction C2938 C2938 C2938
Left Bracket for all other drawers in PWD & APC Construction C2937 C2937 C2937
Right Bracket for Tall Cabinet Drawers in PWD & APC Construction C2940 C2940 C2940
Left Bracket for Tall Cabinet Drawers in PWD & APC Construction C2939 C2939 C2939
Right Slide for Drawers in PWD & APC Construction C3074 C3076 C3078
Left Slide for Drawers in PWD & APC Construction C3075 C3077 C3079
Bracket for Peninsula Drawers in PWD & APC Construction ( Price per Set) C3070 C3070 C3070
Right Slide for Peninsula Drawers in PWD & APC Construction C2964 C2963 C2962
Left Slide for Peninsula Drawers in PWD & APC Construction C2959 C2958 C2957
Wellborn recommends that all countertops be caulked underneath the sink. This is
to help prevent water seepage into the endgrain of the cabinet frame members and
door members. Bullnose countertops, no matter the composition of the top, must be
caulked at the time of installation.
Caulk Countertop
Waterproof
Caulk/Sealant
Face Frame
Countertop
HELPFUL HINT
DRAWER SLIDES
Item Code Description
FADS12KIT FULL ACCESS 9” DRAWER SLIDE KIT
FADS15KIT FULL ACCESS 12” DRAWER SLIDE KIT
FADS18KIT FULL ACCESS 15” DRAWER SLIDE KIT
FADS21KIT FULL ACCESS 18” DRAWER SLIDE KIT
FADS24KIT FULL ACCESS 21” DRAWER SLIDE KIT
