4. Suggested Hardware to Keep in Stock
ITEM
RECOMMENDED
HARDWARE
DESCRIPTION
QTY TO STOCK
Wall Rail
WRL96
6 pcs
Rail Covers
Stock depends on the finish most often used
Bridge Support
Stock depends on the finish most often used
Panel Hanger Left
C3174PK5
1 pk of 5
Panel Hanger Right
C3175PK5
1 pk of 5
Hanger Covers Left
Stock depends on the finish most often used
Hanger Covers Right
Stock depends on the finish most often used
Cam Fastener
C3169PK100
Pk of 100
Cam Covers
Stock depends on the finish most often used
5MM Connecting Bolt
C3171PK50
Minimum 2 pks of 50
Push Thru 2 Sided Connecting Bolt C3172PK50
1 pk of 50
Snaptoggle Kit
SNAPTOGGLEKIT
1 kit
Machine Bolt
C3177PK100
1 pk of 100
Euro Screw
C3178PK50
4 pks of 50
Clip On Hinges
C2202PK10
2 pks of 10
#8, 2½” Panhead Screws
B7942PK25
2 pks of 25
#8, 2” HiLo Screws
B7941PK100
2 pks of 100
Screw Covers
Stock depends on the finish most often used
Angle Bracket
Stock depends on the finish most often used
5MM Nickel Plated Shelf Support
C3173PK50
2 pks of 50
Bumper
C3179PK200
1 pk of 200
Wardrobe Tube (round)
Stock depends on the finish most often used
Wardrobe Tube Supports (round)
Stock depends on the finish most often used
Oval Wardrobe Tube
Stock depends on the finish most often used
Oval Wardrobe Tube Supports
Stock depends on the finish most often used
TEMPLATE
ITEM
RECOMMENDED
ANDTOOLS
DESCRIPTION
QTY TO STOCK
Jig for Cam Fastener Holes
C2579
1 jig per crew
Cam Fastener Depth Gauge
C2574
1 gauge per install crew
Cam Fastener Drill Bit
C2575
Minimum 2 per crew
Shoe Fence Depth Gauge
C2577
1 gauge per install crew
Shoe Fence Drill Bit
C2578
Minimum 2 per crew
