ISLAND COMPONENTS (continued)
• Reduced Depth option available in 3”
increments to 15”
•
3
⁄
4
” Unfinished plywood flush ends
standard
• Functional drawers on front with drawer
blank on back
ICSDU15
ICSDU18
ICSDU21
ICSDU24
Island Component Single Drawer Unit
24
12
15, 18, 21, 24
•
Must specify L or R hinge
• Reduced depth option available in 3”
increments to 15”
•
3
⁄
4
” Unfinished plywood flush ends
standard
Island Component Door Unit
ICDU15 L/R
ICDU18 L/R
ICDU21 L/R
15,18,21
24
12
15,18
24
12
ICBU15
ICBU18
Island Component Basket Unit
• Framed construction
• Basket functional front and back
• Reduced Depth option not available
•
3
⁄
4
” Unfinished plywood flush ends
standard
• Finished interior standard
• Finish techniques are not included
ISLAND COMPONENT BASE ENDS WITH LEGS
ICBE24CRTL
Island Component Base End with Chunky Rope Legs
ICBE24CFTL
Island Component Base End with Chunky Fluted Legs
ICBE24CCTL
Island Component Base End with Chunky Classic Legs
ICBE24CSTL
Island Component Base End with Chunky Shaker Legs
• Ends finished on both sides
• Reversible for left or right application
• For MDF and Thermofoil door styles,
component base ends are painted maple
• Reduced Depth option available in 3”
increments to 15”
When specifying:
RD21 actual depth is 22
1
⁄
2
”
RD18 actual depth is 19
1
⁄
2
”
RD15 actual depth is 16
1
⁄
2
”
• Increased Depth option available in 3”
increments to 48”
When specifying:
ID27 actual depth is 28
1
⁄
2
”
ID30 actual depth is 31
1
⁄
2
”
ID33 actual depth is 34
1
⁄
2
”
ID36 actual depth is 37
1
⁄
2
”
ID39 actual depth is 40
1
⁄
2
”
ID42 actual depth is 43
1
⁄
2
”
ID45 actual depth is 46
1
⁄
2
”
ID48 actual depth is 49
1
⁄
2
”
*
16
1
⁄
2
” W x 12” H inside dimension
34
1
/
2
4
1
/
2
25
1
/
2
*
*
34
1
/
2
12
5
4
1
/
2
25
1
/
2
*
34
1
/
2
12
5
4
1
/
2
25
1
/
2
*
34
1
/
2
12
5
4
1
/
2
25
1
/
2
*
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
12” 24”
12” 30”
Semi-Custom
