556 / 878
Premier–3–44
BASE ACCESSORIES (continued)
• Includes wood spacers
• Must be installed between two cabinets
• An overlay filler trim is recommended for
FOL door styles
• Can be installed next to a cabinet with
Flush Cabinet End option by omitting
supplied spacers
• Natural finished wood with chrome rails
• If not installed between 2 cabinets,
exposed end must be covered with an end
panel
• Full extension slides
• Finish techniques are not included
2 Adj. shelves,
1 Fixed shelf
Base Filler Pullout
BFP3
BFP6
23
30
3, 6
3, 6
30
23
Base Filler Peg Pullout
BFPP3L
BFPP6L
BFPP3R BFPP6R
• Natural finished wood with stainless steel
perforated panel pullout
• An overlay filler trim is recommended for
FOL door styles
• Can be installed next to a cabinet with
Flush Cabinet End option by omitting
supplied spacers
• If not installed between 2 cabinets,
exposed end must be covered with an end
panel
• Full extension slides
• Assortment of stainless steel black coated
hooks and pegs
• Finish techniques are not included
Right Hand Shown
Cope and Tenon
One Piece
Two Pieces
34
1
/
2
24
Matching Base End Panel
MBEP
IMBEP
MBEPSD
•
3
⁄
4
” Solid wood construction with spacers
on back to compensate for the face frame
scribe
• All MBEPs are square on top and bottom
edge
• TOL door styles have a decorative profile
on the sides
• FOL door styles have matching door edge
profile on the sides and are designed to
flush with the face frame of the cabinet
• Harmony/Geneva/Venice/Napa/Sonoma/
Savannah/Hawthorne/Monterey/Sydney
have a mitered profile
• Barcelona and Milan are slab with
separate toe kick construction
• For Thermofoil door styles, Matching End
Panels are thermofoiled fiberboard
• For MDF door styles, Matching End
Panels are painted MDF
• INSET:
Use codes beginning with ‘I’
Miter/Slab
3
/
4
" Solid Wood
Finished (4) sides
4
1
/
2
30
24
Semi-Custom
APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL
•
•
INS
•
•
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
