MATCHING WALL END PANELS
CLEAR GLASS SHELVES
GLASS SHELF CLIPS
12
•
3
⁄
4
” Solid wood construction with spacers
on back to compensate for the face frame
scribe
• TOL door styles are square on top and
bottom with a decorative profile on the
sides
• FOL door styles are
7
⁄
8
” shorter, have
matching door edge profiles on all 4 sides
and are designed to flush with the face
frame of the cabinet
• Harmony/Geneva/Venice/Napa/Sonoma/
Savannah/Monterey/Hawthorne/Sydney
have a mitered profile
• When reducing panels, RD9 will be square
in TOL arch and all cathedral door styles
• For Thermofoil door styles, Matching End
Panels are thermofoiled fiberboard
• For MDF door styles, Matching End
Panels are painted MDF
• 54”, 57” and 60” will be double panel
except on miter door styles
•
INSET:
Use codes beginning with ‘I’
MWEP51
IMWEP51
MWEP54
IMWEP54
MWEP57
IMWEP57
MWEP60
IMWEP60
12
50
1
/
8
,
53
1
/
8
,
56
1
/
8
,
59
1
/
8
12
Note: Due to dimensions, an MFE or skin
must be ordered to cover exposed ends on
all FOL finishes with Natural Ends and
PCE or APC construction wall cabinets.
Another option is to use matching toe kick
to cover.
Miter
Glass Shelf Clips
• 5mm diameter padded glass shelf supports
• Codes indicate cabinet width that shelf fits
•
1
⁄
4
” Thick
• Glass Shelf Clips included
•
INSET:
Use codes beginning with ‘I’
DC
DC FI
ERC
CG
ERC FI
