475 / 878
Premier–2–71
CCWH3636D CCWH3648D
CCWH4236D CCWH4248D
CCWH4836D CCWH4848D
CCWH5436D CCWH5448D
CURVED CONTEMPORARY WOOD HOOD
36,42,48,54
*
20
1
/
2
,
26
1
/
2
,
32
1
/
2
,
38
1
/
2
23
27,
39
36,
48
5 9
CCWH3636 CCWH3648
CCWH4236 CCWH4248
CCWH4836 CCWH4848
CCWH5436 CCWH5448
* Actual width dimensions including moulding:
CCWH36 — 40”
CCWH42 — 46”
CCWH48 — 52”
CCWH54 — 58”
• Use with CMNY36P, CMNY42P,
CMNY48P, CMNY54P
• Small Cove Moulding (SCVM8) is applied
to hood for a clean “finished” look
• No extended heights
• For MDF and Thermofoil door styles,
wood hoods are painted maple
DESIGNER CURVED CONTEMPORARY WOOD HOOD
36,42,48,54
20
1
/
2
,
26
1
/
2
,
32
1
/
2
,
38
1
/
2
23
27,
39
36,
48
5 9
*
* Actual width dimensions including moulding:
CCWH36D — 40”
CCWH42D — 46”
CCWH48D — 52”
CCWH54D — 58”
• Use with CMNY36D, CMNY42D,
CMNY48D, CMNY54D
• Small Cove Moulding (SCVM8) is applied
to hood for a clean “finished” look
• No extended heights
• Shaded area is maple plywood, may have
overspray from finishing and allows for
field application of paints, tile or other
decorative material; staining is NOT
recommended
• This product will not be covered under
warranty once alterations of any kind
have been made
• For MDF and Thermofoil door styles,
wood hoods are painted maple
INTEGRAL WOOD HOODS
24
19
1
/
2
30, 36, 42
7
3
/
4
12
26, 32, 38
19
1
/
2
7
3
/
4
24
12
30, 36, 42
26, 32, 38
19
1
/
2
7
3
/
4
24
12
26, 32, 38
30, 36, 42
Plain Integral Wood Hood
IWH3024P
IWH3624P
IWH4224P
• Designed for installation between
standard depth wall cabinets
• For MDF and Thermofoil door styles,
hoods are painted maple
Integral Wood Hood
IWH3024
IWH3624
IWH4224
Beaded Integral Wood Hood
IWH3024B
IWH3624B
IWH4224B
• Designed for installation between standard
depth wall cabinets
• For MDF and Thermofoil door styles,
hoods are painted maple
• Designed for installation between standard
depth wall cabinets
• For MDF and Thermofoil door styles,
hoods are painted maple
