Select –4–1
A
ll
base
cabinets have
square doors
.
ACTIVE LIVING CABINETS
• Can be used as a blind corner cabinet by
removing one door
2 Doors,
1 Adj. shelf
ACB30
ACB33
ACB36
ACB39
ACB42
ACB45
ACB48
2 Doors w/o center mullion,
1 Adj. shelf
ACB24
ACB27
•
Must specify L or R hinge
1 Door,
1 Adj. shelf
ACB15 L/R
ACB18 L/R
ACB21 L/R
Active Living Base Cabinet
AC3DB15
ACB24
V36
ACBBC36R
ACB18
SINK
AREA
Active Living cabinets have 8
1
⁄
2
” high x 7
1
⁄
2
” deep toe kick. All Arch
styles have Square doors in 32
1
⁄
2
” high Active Living Cabinets. All
single door cabinets must specify left or right hinge.
Active Living cabinetry is available in all Select door styles.
Design Example of Active Living Base Cabinets
24 30, 33, 36, 39, 42, 45, 48
8
1
/
2
32
1
/
2
7
1
/
2
24
32
1
/
2
24, 27
8
1
/
2
7
1
/
2
Maximum/Minimum Pull Measurements
TOL FOL
ACB30
maximum pull
40¾” 40¾”
minimum pull
39” 40¾”
ACB33
maximum pull
42¼” 42¼”
minimum pull
40½” 42¼”
ACB36
maximum pull
43¾” 43¾”
minimum pull
42” 43¾”
ACB39
maximum pull
45¼” 43½”
minimum pull
43½” 43½”
ACB42
maximum pull
46¾” 45”
minimum pull
45” 45”
ACB45
maximum pull
48¼” 46½”
minimum pull
46½” 46½”
ACB48
maximum pull
49¾” 48”
minimum pull
48” 48”
Sink Cut Out Dimensions
ACSA30
29” x 22¾”
ACSA36 35” x 22¾”
• ½” Plywood
2 Drawer blanks
ACSA30
ACSA36
Active Living Sink Apron
30, 36
5
1
/
2
24
Semi-Custom
APC BO ES FCE FDBS FH FI FIMD FO ID MFE P PCE PWD RD RTK TKA VTK WCM WDSC
