• ¾” Plywood
• Diagonal transitional moulding
available in moulding section
• Finish techniques are not included
• For MDF and Thermofoil door
styles, panel is painted maple
• Panel will not work with cabinets
that have Flush Cabinet End (FCE)
option
Corner Tall End Panel
CTEP84
CTEP87
CTEP90
CTEP93
CTEP96
Installation Diagram
A=Cabinet Width
24
27
30
33
36
B=Distance from
Corner
41
43
1
⁄
16
45
3
⁄
16
47
3
⁄
16
49
7
⁄
16
C=Optional Wall
Location
31
33
1
⁄
8
35
1
⁄
4
37
3
⁄
8
39½
24
A
Cabinet
Optional Wall
45°
C
B
CTEP
Wall
Wall
•
3
⁄
16
” Plywood
• Order finish same as cabinets
• Specialty Finishes available
• Finish techniques are not included
• For MDF and Thermofoil door
styles, panel is painted maple
FBP4896V
(Veneer)
Finish Back Panel (continued)
Finish Back Panel
FBP4836V
(Veneer)
FBP4848V
(Veneer)
•
3
⁄
16
” Plywood
• Order finish same as cabinets
• Specialty Finishes available
• Finish techniques are not included
• For MDF and Thermofoil door
styles, panels are painted maple
PANELS (continued)
• ½” Veneer MDF core panel
• Order finish same as cabinets
• Finish techniques are not included
• For MDF and Thermofoil door
styles, panel is painted maple
1/2FBP9648V
(Veneer)
FBP9648V
(Veneer)
•
3
⁄
16
” Plywood
• Order finish same as cabinets
• Finish techniques are not included
• For MDF and Thermofoil door
styles, panel is painted maple
Finish Back Panel (continued)
Finish Back Panel (continued)
3/4FBP4896
(Veneer)
• ¾” Veneer core panel
• Order finish same as cabinets
• Finish techniques are not included
• For MDF and Thermofoil door
styles, panel is painted maple
Finish Back Panel (continued)
