560 / 872
Premier–3–48
ISLAND COMPONENT BASE ENDS WITH LEGS (continued)
ICBE24MSP
Island Component Base End with Mission Square Posts
• Available in cherry, maple and oak
• Ends finished on both sides
• Reversible for left or right application
• Post will be profiled on the two outside
faces and smooth on the two faces that
attach to the cabinet and side panel
• For MDF and Thermofoil door styles,
component base ends are painted maple
• Reduced Depth option available in 3”
increments to 15”
When specifying:
RD21 actual depth is 22
1
⁄
2
”
RD18 actual depth is 19
1
⁄
2
”
RD15 actual depth is 16
1
⁄
2
”
• Increased Depth option available in 3”
increments to 48”
When specifying:
ID27 actual depth is 28
1
⁄
2
”
ID30 actual depth is 31
1
⁄
2
”
ID33 actual depth is 34
1
⁄
2
”
ID36 actual depth is 37
1
⁄
2
”
ID39 actual depth is 40
1
⁄
2
”
ID42 actual depth is 43
1
⁄
2
”
ID45 actual depth is 46
1
⁄
2
”
ID48 actual depth is 49
1
⁄
2
”
*
16
1
⁄
2
” W x 12” H inside dimension
• Recommended for islands 36” wide or
wider
• Trimmable
• Finish techniques are not included
ICCS
Island Component Center Support
34
1
/
2
3 3
ICCS
4
1
/
2
25
1
/
2
34
1
/
2
12
ISLAND COMPONENT SHELVES
Note: When ordering component
shelf, the overall dimension of the
island will correspond with the
correct shelf size. For example, if
you are building a 39” wide island,
order an ICS39 shelf.
39, 42, 45, 48, 51, 54,
57, 60, 63, 72, 84, 96
16
1
/
2
3
3
/
4
Island Component Shelf
ICS39
ICS42
ICS45
ICS48
ICS51
ICS54
ICS57
ICS60
ICS63
ICS72
ICS84
ICS96
Actual width:
ICS39 37
1
⁄
2
” ICS48 46
1
⁄
2
” ICS57 55
1
⁄
2
” ICS72 70
1
⁄
2
”
ICS42 40
1
⁄
2
” ICS51 49
1
⁄
2
” ICS60 58
1
⁄
2
” ICS84 82
1
⁄
2
”
ICS45 43
1
⁄
2
” ICS54 52
1
⁄
2
” ICS63 61
1
⁄
2
” ICS96 94
1
⁄
2
”
•
3
⁄
4
” Thick plywood shelf with CEMB
moulding applied to all sides
• Two support rails and brackets included
for shelf support. Must be field installed.
• Not trimmable
• Must specify finish
• For MDF and Thermofoil door styles,
shelf is painted maple
• Reduced Depth option available in 3”
increments to 15”
When specifying:
RD21 actual depth is 13
1
⁄
2
”
RD18 actual depth is 10
1
⁄
2
”
RD15 actual depth is 7
1
⁄
2
”
• Increased Depth option available in 3”
increments to 48”
When specifying:
ID27 actual depth is 19
1
⁄
2
”
ID30 actual depth is 22
1
⁄
2
”
ID33 actual depth is 25
1
⁄
2
”
ID36 actual depth is 28
1
⁄
2
”
ID39 actual depth is 31
1
⁄
2
”
ID42 actual depth is 34
1
⁄
2
”
ID45 actual depth is 37
1
⁄
2
”
ID48 actual depth is 40
1
⁄
2
”
• Finish techniques are not included
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
Semi-Custom
APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL
s
•
s
s
•
INS
s
•
s
s
•
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
Semi-Custom
APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL
s
•
•
INS
s
•
•
