Premier–5–5
U128724SS L/R
U158724SS L/R
U188724SS L/R
U218724SS L/R
U248724SDSS L/R
•
Must specify L or R hinge
• RD available to 12” depth only
• Toe kick shipped attached
• For Inverted Frame option, toe kick is
shipped unattached
• For MDF and Thermofoil door styles,
sliding shelves are natural finished solid
wood
•
INSET:
12” wide not available
•
Must specify L or R hinge
• RD available to 12” depth only
• Toe kick shipped attached
• For Inverted Frame option, toe kick is
shipped unattached
• For MDF and Thermofoil door styles,
sliding shelves are natural finished solid
wood
•
INSET:
12” wide not available
84” High Utility Cabinet with Sliding Shelves
87” High Utility Cabinet with Sliding Shelves
2 Doors,
1 Full depth adj. shelf in
upper section,
4 Sliding shelves in lower
section
2 Doors,
1 Full depth adj. shelf in
upper section,
4 Sliding shelves in lower
section
U128424SS L/R
U158424SS L/R
U188424SS L/R
U218424SS L/R
U248424SDSS L/R
90” High Utility Cabinet with Sliding Shelves
U129024SS L/R
U159024SS L/R
U189024SS L/R
U219024SS L/R
U249024SDSS L/R
2 Doors,
1 Full depth adj. shelf in
upper section,
4 Sliding shelves in lower
section
•
Must specify L or R hinge
• RD available to 12” depth only
• Toe kick shipped attached
• For Inverted Frame option, toe kick is
shipped unattached
• For MDF and Thermofoil door styles,
sliding shelves are natural finished solid
wood
•
INSET:
12” wide not available
Sliding shelves have
5
⁄
8
” hardwood sides, front and back,
3
⁄
16
” plywood bottom, adjustable mounting brackets and are dovetail full extension soft
close. The sliding shelves have a 75 lb. weight capacity. Toe kicks shipped attached for all 84” - 102” high cabinets. To order with toe kick
shipped unattached specify TKU with item code (For example, U249624SS TKU). See Semi-Custom Program for additional details. INSET:
Sliding shelves are attached to full depth shelves.
UTILITY CABINETS WITH SLIDING SHELVES INSTALLED
24
84
21
12, 15, 18, 21, 24
3
1
/
2
24
90
21
12, 15, 18, 21, 24
3
1
/
2
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
12” 24” 72” 84” 18” 30”
Semi-Custom
APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL
• • • •
• • • • • • • • • •
s
• •
•
INS
• • • •
• • • • • • • • •
s
• •
•
24
87
21
12, 15, 18, 21, 24
3
1
/
2
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
12” 24” 84
1
/
4
” 87” 18” 30”
Semi-Custom
APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL
• • • •
• • • • • • • • • •
s
• •
•
INS
• • • •
• • • • • • • • •
s
• •
•
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
12” 24” 87
1
/
4
” 90” 18” 30”
Semi-Custom
APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL
• • • •
• • • • • • • • • •
s
• •
•
INS
• • • •
• • • • • • • • •
s
• •
•
