Premier–4–1
ACTIVE LIVING CABINETS
AC3DB15
ACB24
V36
ACBBC36R
ACB18
SINK
AREA
Active Living cabinets have 8
1
⁄
2
” high x 7
1
⁄
2
” deep toe kick. All Cathedral and
Arch styles have Square doors in 32
1
⁄
2
” high Active Living Base Cabinets. All
single door cabinets must specify left or right hinge.
Active Living cabinetry is available in all Premier overlay door styles only.
Design Example of Base Cabinets
Active Living Base Cabinet
ACB15 L/R
ACB18 L/R
ACB21 L/R
1 Door,
1 Adj. shelf
•
Must specify L or R hinge
• INSET:
Not available
• INSET:
Not available
2 Doors w/o center mullion,
1 Adj. shelf
ACB24
ACB27
24
32
1
/
2
24, 27
8
1
/
2
7
1
/
2
• Can be used as a blind corner cabinet by
removing one door
• INSET:
Not available
2 Doors,
1 Adj. shelf
ACB30
ACB33
ACB36
ACB39
ACB42
ACB45
ACB48
24 30, 33, 36, 39, 42, 45, 48
8
1
/
2
32
1
/
2
7
1
/
2
Maximum/Minimum Pull Measurements
TOL FOL
ACB30
maximum pull 40
3
/
4
” 40
3
/
4
”
minimum pull 39” 40
3
/
4
”
ACB33
maximum pull 42
1
/
4
” 42
1
/
4
”
minimum pull 40
1
/
2
” 42
1
/
4
”
ACB36
maximum pull 43
3
/
4
” 43
3
/
4
”
minimum pull 42” 43
3
/
4
”
ACB39
maximum pull 45
1
⁄
4
” 43
1
⁄
2
”
minimum pull 43
1
⁄
2
” 43
1
⁄
2
”
TOL FOL
ACB42
maximum pull 46
3
⁄
4
” 45”
minimum pull 45” 45”
ACB45
maximum pull 48
1
⁄
4
” 46
1
⁄
2
”
minimum pull 46
1
⁄
2
” 46
1
⁄
2
”
ACB48
maximum pull 49
3
⁄
4
” 48”
minimum pull 48” 48”
30, 36
5
1
/
2
24
ACSA30
ACSA36
Active Living Sink Apron
2 Drawer blanks
•
1
⁄
2
” Plywood
•
INSET:
Not available
Sink Maximum Cut Out Dimensions
ACSA30 29” x 22
3
⁄
4
”
ACSA36 35” x 22
3
⁄
4
”
Available with
WCM Option
24
32
1
/
2
30, 33, 36
8
1
/
2
7
1
/
2
ACSB30
ACSB33
ACSB36
Active Living Sink Base Cabinet
1 Drawer blank
•
1
⁄
2
” Plywood
• Removable front panel
•
INSET:
Not available
Sink Maximum Cut Out Dimensions
ACSB30 29” x 22
3
⁄
4
”
ACSB33 32” x 22
3
⁄
4
”
ACSB36 35” x 22
3
⁄
4
”
32
1
/
2
7
3
/
4
5
27
5
1
/
2
24
30,33,36
WIDTH
HEIGHT
DEPTH
Min.
Max.
Min.
Max.
Min.
Max.
9” 48” 24” 48” 6” 30”
Semi-Custom
APC BO CC ES FCE FDBS FH FI FIMD FO ID IF IME MFE MD MH MW P PCE RD RTK TKA VTK WBR WCM WS WTR
FOL/TOL
• • • • • •
