Cabinet components are machine sanded to prepare the surface for staining. Wellborn hand rubs the stain to enhance the natural wood grain.
Three coats of finish, including two coats of high moisture resistant sealers and one top coat of high molecular weight synthetic catalyzed
varnish, result in a durable finish. Natural finishes receive two coats of sealer and one top coat.
The Select Series has a machine sanded finishing
process and does not include the detailed hand sanding technique featured in the Premier Series. Wellborn Cabinet, Inc. does not recommend
designs combining these series.
F
ace
F
rames
1¾” x ¾” Thick kiln-dried solid wood stile and rail members. The center stiles are ¾” x 3½” solid wood. On all blind corner base and blind
corner wall cabinets, the center stiles are ¾” x 6½” solid wood. 48” Blind corner base has 9½” center stile. All face frame joints are precisely
aligned with blind mortise and tenon, glued and stapled at all joints.
E
nd
P
anels
½” Thick industrial grade furniture board with complementing wood grain, White or Linen laminate exterior resistant to household chemicals.
Interior is wood grain or white laminate. For White and Linen laminate interior will be white. The top and bottom edges of wall cabinet end
panels are banded with wood grain or white edge banding. End panels are machined to accept tops, bottoms and back panels.
W
all
C
abinet
T
ops
and
B
ottoms
& B
ase
C
abinet
B
ottoms
½” Thick industrial grade furniture board. These components are laminated with wood grain or white laminate. A dado joint, glue and staples
are used to attach the top and bottom into face frames, end panels and hanging rails.
B
acks
All backs are
1
⁄
8
” thick wood grain or white MDF printed on the interior side. Wall cabinet backs are reinforced with
11
⁄
16
” x
3½” laminated fiberboard hanging rails at the top and bottom. Wall cabinet backs are recessed and stapled into end panels,
hanging rails and shelves. Base cabinet backs are attached in the same manner; the top and bottom of the base cabinet have
11
⁄
16
” x 3½” laminated fiberboard hanging rails securing the back to the top of the end panel.
S
helves
Wall Cabinets — Adjustable Shelves
All wall cabinet shelves are adjustable and made of ¾” thick industrial grade furniture board. The shelves are laminated with a wood grain
or white laminate which is resistant to water and household chemicals. The front edge of the shelf is banded with wood grain or white edge
banding. The cabinet sides are drilled for shelf supports which are adjustable at 2½” increments.
Base Cabinets — Adjustable Shelves
All base cabinets have fully adjustable ¾” thick industrial grade furniture board shelves. The shelves are 10
9
⁄
16
” deep and laminated with a wood
grain or white laminate. The front edge is banded with a wood grain or white edge banding.
B
ase
T
oe
B
oard
The toe kick for base, vanity, utility and oven cabinets is ½” x 4½”— industrial grade furniture board. Toe kicks are unfinished and have rodent
proof captive construction.
D
rawer
— I
nner
B
ox
C
onstruction
Sides, Sub-Front and Back
The inner box construction includes ¾” wood grain or white furniture board drawer sides, and ½” sub-front and back. All backs and
sub-fronts are tenoned into the sides, glued and stapled. The drawer box is screwed to the drawer front with four screws and is a full depth
drawer. The drawer has a 75 lb. weight capacity.
Bottoms
1
⁄
8
” Wood grain or white printed hardboard drawer bottoms dadoed to accept both sides, glued and stapled.
D
rawer
S
lides
Drawers have epoxy coated side mount captive slides that provide smooth, easy operation. The slide has positive stop opening and
self-closing features. Drawer slides fit into a bracket mounted to the hanging rail. The bracket allows horizontal drawer adjustability.
6–W
ay
A
djustable
C
oncealed
H
inges
Hinges are 6-way adjustable, chrome finished and self-closing with a concealed hinge design.
THE SELECT SERIES — STANDARD CONSTRUCTION SPECIFICATIONS
